MERIDA. MORE BIKE.
Manufactured in Taiwan, the hub of the cycling industry, using cutting-edge frame technologies, which are developed and tested in Germany. Featuring top-quality, state-of-the-art components.
MERIDA sponsors top professional cycling teams including Road Team BAHRAIN VICTORIOUS, MTB Merida Factory Racing, MTB D2mont Merida, and others. They also support athletes such as Kristin Atzeni, Tom Wheeler, Lennard Heidenreich, Anders Backe, Elisabeth Brandau, and more.
Any remaining doubts? One of the best things about MERIDA Bikes is that the manufacturer offers a LIFETIME warranty on frames (exclusions may apply).
Bicycle technical specifications
Frame and suspension
Frame:
CROSSWAY TFS III; MAT aluminium; 700x50C max. WHS; 135×9 AST; BSA BBR
Fork:
Suntour NX1-DS-LO-700C-63; Coil; 63 STR; Lockout; 700x50C max. WHS
Drivetrain
Rear derailleur:
Shimano CUES U6020 10S
Front derailleur:
Shimano CUES U6010
Shifters:
Shimano CUES U6000 / Shimano CUES U6000
Crankset:
Shimano CUES U4010; 46-30 ATC Crank length: 170 mm-XXS/XS/S, 175 mm-M/XL
Cassette:
Shimano LG300; 11-39 ATC; 10 GER
Chain:
KMC xGlide
Bottom bracket:
Shimano MT501
Pedals:
VP VPE-891
Brake system
Brakes:
Shimano MT200; 2 piston / Shimano MT200; 2 piston
Brake discs:
Shimano RT10; 160mm / Shimano RT10; 160mm
Cockpit
Handlebar:
MERIDA COMP CC; MAT aluminium; 660 WHB; 25 RHB
Stem:
MERIDA COMP TK; MAT aluminium; 31.8 DSH; adjustable / Length: XXS/XS/S/M: 95 mm, L/XL: 110 mm
Grips:
MERIDA EXPERT EC
Headset:
MERIDA M2346 Neck
Wheels
Wheel size:
28″
Rims:
MERIDA COMP TK; 20 IWR; 17 HRI; MAT aluminium
Front hub:
Shimano QC300; 100×9 WHF; 32 SPH; Centerlock
Front tire:
Maxxis Overdrive Excel; 700x40C; wire; reflective stripe, Silkshild
Rear tire:
Maxxis Overdrive Excel; 700x40C; wire; reflective stripe, Silkshild
Spokes:
Black stainless
Saddle and components
Saddle:
MERIDA Cross Sport
Seat post:
MERIDA EXPERT; 30.9 DSP; 15 SSB; XXS, XS: 300mm; S, M: 350mm; L, XL: 400mm
Seat post clamp:
MERIDA EXPERT
Accessories
Bell:
YWS-Alloy
